Model #5061
Student line
Technical Specifications:
Bore: ML (11,658mm/0.459")
Bell: #S1 (120mm/4.72")
Bell material: Yellow brass
Leadpipe: #S1
Tuning slide: Round
Valves material: Monel
Valves section: Yellow brass
Trim kit: Silver plated
Finish: Silver plated 1000 thousandth
Model #5000
Student line
Technical Specifications:
Bore: ML (11,658mm/0.459")
Bell: #25 (120mm/4.72")
Bell material: Yellow brass
Leadpipe: #3
Tuning slide: Round
Valves material: Monel
Valves section: Yellow brass
Trim kit: Silver plated
Finish: Silver plated 1000 thousandth
Model #5009
Student line
Technical Specifications:
Bore: M (11,43mm/0.450")
Bell: #25 (120mm/4.72")
Bell material: Yellow brass
Leadpipe: #3
Tuning slide: Round
Valves material: Monel
Valves section: Yellow brass
Trim kit: Silver plated
Water keys: 3
Finish: Silver plated 1000 thousandth
Model #5048
Professional line
Technical Specifications:
Bore: ML (11,658mm/0.459")
Bell: #27 (120mm/4.72")
Bell material: Yellow brass
Leadpipe: #3
Valves material: Monel
Valves section: Yellow brass
Trim kit: Silver plated
Finish: Silver plated 1000 thousandth
Model #5330
Professional line
Technical Specifications:
Bore: ML (11,658mm/0.459")
Bell: #27 (120mm/4.72")
Bell material: Yellow brass
Leadpipe: #3
Valves material: Monel
Tuning slide: Round
Valves material: Monel
Valves section: Yellow brass
Trim kit: Gold plated
Finish: Silver plated 1000 thousandth
Model #5335
Professional line
Technical Specifications:
Bore: ML (11,658mm/0.459")
Bell: #27 (120mm/4.72")
Bell material: Yellow brass
Leadpipe: #3 REVERSE
Valves material: Monel
Tuning slide: Round
Valves material: Monel
Valves section: Yellow brass
Trim kit: Gold plated
Finish: Silver plated 1000 thousandth
Model #5305
Student line
Technical Specifications:
Bore: ML (11,658mm/0.459")
Bell: #27 (120mm/4.72")
Bell material: Yellow brass
Leadpipe: #3 LIGHT
Tuning slide: Round
Valves material: Monel
Valves section: Yellow brass
Trim kit: Silver plated
Finish: Silver plated 1000 thousandth
Model #5311
Professional line
Technical Specifications:
Bore: XL (11,90mm/0.469")
Bell: #27 (120mm/4.72")
Bell material: Yellow brass
Leadpipe: #1
Tuning slide: Round
Valves material: Monel
Valves section: Yellow brass
Trim kit: Titanium
Finish: Silver plated 1000 thousandth
Model #5063 Silver plated / Model #5066 Lacquered
Professional line
Technical Specifications:
Bore: ML (11,658mm/0.459")
Bell: #S3 (130mm/5.12")
Bell material: Bellflex
Leadpipe: #S3 REVERSE
Tuning slide: Square
Valves material: Monel
Valves section: Yellow brass
Trim kit: Silver plated
Finish: Silver plated 1000 thousandth
Model #5313
Professional line
Technical Specifications:
Bore: ML (11,658mm/0.459")
Bell: #27 (120mm/4.72")
Bell material: Yellow brass
Leadpipe: #3 REVERSE
Tuning slide: Square
Valves material: Monel
Valves section: Yellow brass
Trim kit: Titanium
Finish: silver plated 1000 thousandth
Model #5360-II
Maestro line
Technical Specifications:
Bore: PB*
Bell: VRII (120mm/4.72")
Bell material: Bellflex
Leadpipe: #VRII REVERSE
Tuning slide: Square & round
Valves material: Monel
Valves section: Yellow brass
Trim kit: Gold plated
Finish: Silver plated 1000 thousandth
Model #5381
Maestro line
Technical Specifications:
Bore: ML (11,658mm/0.459")
Bells: #25 & #27 (120mm/4.72")
Bells material: #25 Copper silver plated & #27 Bellflex gold plated
Leadpipes: #1 & #3
Main tuning slides: #25 & #27
Valves material: Monel
Valves section: Yellow brass
Trim kit: Gold plated
Finish: Silver plated 1000 thousandth
Model #5320 Bellflex / Model #5329 Cooper
Maestro line
Technical Specifications:
Bore: ML (11,658mm/0.459")
Bells: #25 or #27 (120mm/4.72")
Bells material: Bellflex or Copper
Leadpipes: #1 or #3 REVERSE
Tuning slide: Square & round
Valves material: Monel
Valves section: Yellow brass
Trim kit: German silver
Finger buttons: Onyx
Finish: Silver plated 1000 thousandth
Model #5490 Silver plated / Model #5491 Raw brass
Maestro line
Technical Specifications:
Bore: 11,20mm/0.441"
Bell: #28 (140mm/5.51")
Bell material: Bellflex, Gold brass or Copper
Leadpipes: #3 & #5
Rotary valves: Yellow brass solid valves
Valve section with bearings
Water key in Bb key
Finish: silver plated 1000 thousandth or raw brass
Model #5391 Bellflex / #5392 Copper
Maestro line
Technical Specifications:
Bore: XL (11,90mm/0.469")
Bell: #27 (125mm/4.92")
Bell material: Bellflex or Copper
Leadpipe: #1 REVERSE
Tuning slide: Square
Valves material: Monel
Valves section: Yellow brass
Trim kit: Titanium
Trigger on 1st slide
4th valve slide F
Finish: Silver plated 1000 thousandth
Model #4000-1
技术参数:
管径: ML (11,658mm/0.459")
喇叭: #ONE
喇叭材质: 黄铜
哨管: #3 反套设计
主调音管: 圆形
活塞材质: 蒙乃尔合金
活塞附件: 黄铜
装饰套件: 镀镍
表面处理: 喷漆
号嘴: 5C
Model #4000-2
技术参数:
管径: ML (11,658mm/0.459")
喇叭口: #24 (120mm/4.72")
喇叭材质: 黄铜
哨管: #3 反套设计
主调音管: 圆形
活塞材质: 蒙乃尔合金
活塞附件: 黄铜
装饰套件: 镀镍
表面处理: 纯净镀银
号嘴: 5C
